    Nadgradna ili ovjesna direktna svjetiljka izrađena iz aluminijskog profila presjeka 60 x 80mm, plastificirana epoxy prahom u jednu od boja: crna, siva, bijela, rusty iron ili antracit siva. Sadrži satinirani ili mikroprizmatični difuzor niveliran s donjim rubom. Izvor svjetla LED samohladivi čvrsti linearni moduli energetske učinkovisti klasa C. LED izvor svjetla klasifikacije MacAdam3, CRI>80, Fotobiološka grupa rizika RG0.

    NAPAJANJE230 V
    IP ZAŠTITAIP40
    KLASA EL. IZOLACIJEI
    SDCM<3
    UČINKOVITOSTdo 133lm/W (MPR)
    UZVRAT BOJE>80
    ŽIVOTNI VIJEKL90B10 60000h 35°C
    POWER FACTOR0.95
    UGR<21 (MPR, SMPR)
    OPTIKA OPAL (M)
    MIKROPRIZMATIK (MPR)
    MAT MIKROPRIZMATIK (SMPR)
    MATERIJAL OPTIKEPMMA
    MATERIJAL KUĆIŠTAALUMINIJ
    UGRADNJANADGRADNA (1)
    OVJESNA (2)
    DOWNLOADUPUTE UKLANJANJA…

    DS Smith

    Slovenija

    KING ICT

    Zagreb

    Oprema

    Ludbreg

    Bolty M1 low power

    TIP

    DIMENZIJE

    LUMEN

    ŠIFRA

    Bolty M1 580 LED 10W LP 830580 x 60 x 80mm895 lm353-231AM-580/10
    Bolty M1 860 LED 14W LP 830860 x 60 x 80mm1342 lm353-231AM-860/14
    Bolty M1 1140 LED 18W LP 8301140 x 60 x 80mm1789 lm353-231AM-1140/18
    Bolty M1 1420 LED 22W LP 8301420 x 60 x 80mm2237 lm353-231AM-1420/22
    Bolty M1 1700 LED 27W LP 8301700 x 60 x 80mm2684 lm353-231AM-1700/27
    Bolty M1 1985 LED 31W LP 8301985 x 60 x 80mm3132 lm353-231AM-1985/31
    Bolty M1 2265 LED 35W LP 8302265 x 60 x 80mm3579 lm353-231AM-2265/35
    Bolty M1 2545 LED 39W LP 8302545 x 60 x 80mm4026 lm353-231AM-2545/39
    Bolty M1 2825 LED 43W LP 8302825 x 60 x 80mm4474 lm353-231AM-2825/43
    Bolty M1 580 LED 10W LP 840580 x 60 x 80mm997 lm353-241AM-580/10
    Bolty M1 860 LED 14W LP 840860 x 60 x 80mm1496 lm353-241AM-860/14
    Bolty M1 1140 LED 18W LP 8401140 x 60 x 80mm1994 lm353-241AM-1140/18
    Bolty M1 1420 LED 22W LP 8401420 x 60 x 80mm2493 lm353-241AM-1420/22
    Bolty M1 1700 LED 27W LP 8401700 x 60 x 80mm2991 lm353-241AM-1700/27
    Bolty M1 1985 LED 31W LP 8401985 x 60 x 80mm3490 lm353-241AM-1985/31
    Bolty M1 2265 LED 35W LP 8402265 x 60 x 80mm3988 lm353-241AM-2265/35
    Bolty M1 2545 LED 39W LP 8402545 x 60 x 80mm4487 lm353-241AM-2545/39
    Bolty M1 2825 LED 43W LP 8402825 x 60 x 80mm4986 lm353-241AM-2825/43

    Bolty M1 high power

    TIP

    DIMENZIJE

    LUMEN

    ŠIFRA

    Bolty M1 580 LED 18W HP 830580 x 60 x 80mm1791 lm353-231AM-580/18
    Bolty M1 860 LED 26W HP 830860 x 60 x 80mm2686 lm353-231AM-860/26
    Bolty M1 1140 LED 35W HP 8301140 x 60 x 80mm3581 lm353-231AM-1140/35
    Bolty M1 1420 LED 43W HP 8301420 x 60 x 80mm4477 lm353-231AM-1420/43
    Bolty M1 1700 LED 51W HP 8301700 x 60 x 80mm5372 lm353-231AM-1700/51
    Bolty M1 1985 LED 59W HP 8301985 x 60 x 80mm6268 lm353-231AM-1985/59
    Bolty M1 2265 LED 68W HP 8302265 x 60 x 80mm7163 lm353-231AM-2265/68
    Bolty M1 2545 LED 76W HP 8302545 x 60 x 80mm8058 lm353-231AM-2545/76
    Bolty M1 2825 LED 85W HP 8302825 x 60 x 80mm8954 lm353-231AM-2825/85
    Bolty M1 580 LED 18W HP 840580 x 60 x 80mm1994 lm353-241AM-580/18
    Bolty M1 860 LED 26W HP 840860 x 60 x 80mm2991 lm353-241AM-860/26
    Bolty M1 1140 LED 35W HP 8401140 x 60 x 80mm3988 lm353-241AM-1140/35
    Bolty M1 1420 LED 43W HP 8401420 x 60 x 80mm4986 lm353-241AM-1420/43
    Bolty M1 1700 LED 51W HP 8401700 x 60 x 80mm5983 lm353-241AM-1700/51
    Bolty M1 1985 LED 59W HP 8401985 x 60 x 80mm6980 lm353-241AM-1985/59
    Bolty M1 2265 LED 68W HP 8402265 x 60 x 80mm7977 lm353-241AM-2265/68
    Bolty M1 2545 LED 76W HP 8402545 x 60 x 80mm8974 lm353-241AM-2545/76
    Bolty M1 2825 LED 85W HP 8402825 x 60 x 80mm9971 lm353-241AM-2825/85

    Bolty MPR1 low power

    TIP

    DIMENZIJE

    LUMEN

    ŠIFRA

    Bolty MPR1 580 LED 10W LP 830580 x 60 x 80mm1007 lm353-231AP-580/10
    Bolty MPR1 860 LED 14W LP 830860 x 60 x 80mm1510 lm353-231AP-860/14
    Bolty MPR1 1140 LED 18W LP 8301140 x 60 x 80mm2013 lm353-231AP-1140/18
    Bolty MPR1 1420 LED 22W LP 8301420 x 60 x 80mm2516 lm353-231AP-1420/22
    Bolty MPR1 1700 LED 27W LP 8301700 x 60 x 80mm3020 lm353-231AP-1700/27
    Bolty MPR1 1985 LED 31W LP 8301985 x 60 x 80mm3523 lm353-231AP-1985/31
    Bolty MPR1 2265 LED 35W LP 8302265 x 60 x 80mm4026 lm353-231AP-2265/35
    Bolty MPR1 2545 LED 39W LP 8302545 x 60 x 80mm4530 lm353-231AP-2545/39
    Bolty MPR1 2825 LED 43W LP 8302825 x 60 x 80mm5033 lm353-231AP-2825/43
    Bolty MPR1 580 LED 10W LP 840580 x 60 x 80mm1122 lm353-241AP-580/10
    Bolty MPR1 860 LED 14W LP 840860 x 60 x 80mm1683 lm353-241AP-860/14
    Bolty MPR1 1140 LED 18W LP 8401140 x 60 x 80mm2244 lm353-241AP-1140/18
    Bolty MPR1 1420 LED 22W LP 8401420 x 60 x 80mm2804 lm353-241AP-1420/22
    Bolty MPR1 1700 LED 27W LP 8401700 x 60 x 80mm3365 lm353-241AP-1700/27
    Bolty MPR1 1985 LED 31W LP 8401985 x 60 x 80mm3926 lm353-241AP-1985/31
    Bolty MPR1 2265 LED 35W LP 8402265 x 60 x 80mm4487 lm353-241AP-2265/35
    Bolty MPR1 2545 LED 39W LP 8402545 x 60 x 80mm5048 lm353-241AP-2545/39
    Bolty MPR1 2825 LED 43W LP 8402825 x 60 x 80mm5609 lm353-241AP-2825/43

    Bolty MPR1 high power

    TIP

    DIMENZIJE

    LUMEN

    ŠIFRA

    Bolty MPR1 580 LED 18W HP 830580 x 60 x 80mm2015 lm353-231AP-580/18
    Bolty MPR1 860 LED 26W HP 830860 x 60 x 80mm3022 lm353-231AP-860/26
    Bolty MPR1 1140 LED 35W HP 8301140 x 60 x 80mm4029 lm353-231AP-1140/35
    Bolty MPR1 1420 LED 43W HP 8301420 x 60 x 80mm5036 lm353-231AP-1420/43
    Bolty MPR1 1700 LED 51W HP 8301700 x 60 x 80mm6044 lm353-231AP-1700/51
    Bolty MPR1 1985 LED 59W HP 8301985 x 60 x 80mm7051 lm353-231AP-1985/59
    Bolty MPR1 2265 LED 68W HP 8302265 x 60 x 80mm8058 lm353-231AP-2265/68
    Bolty MPR1 2545 LED 76W HP 8302545 x 60 x 80mm9066 lm353-231AP-2545/76
    Bolty MPR1 2825 LED 85W HP 8302825 x 60 x 80mm10073 lm353-231AP-2825/85
    Bolty MPR1 580 LED 18W HP 840580 x 60 x 80mm2244 lm353-241AP-580/18
    Bolty MPR1 860 LED 26W HP 840860 x 60 x 80mm3365 lm353-241AP-860/26
    Bolty MPR1 1140 LED 35W HP 8401140 x 60 x 80mm4487 lm353-241AP-1140/35
    Bolty MPR1 1420 LED 43W HP 8401420 x 60 x 80mm5609 lm353-241AP-1420/43
    Bolty MPR1 1700 LED 51W HP 8401700 x 60 x 80mm6731 lm353-241AP-1700/51
    Bolty MPR1 1985 LED 59W HP 8401985 x 60 x 80mm7852 lm353-241AP-1985/59
    Bolty MPR1 2265 LED 68W HP 8402265 x 60 x 80mm8974 lm353-241AP-2265/68
    Bolty MPR1 2545 LED 76W HP 8402545 x 60 x 80mm10096 lm353-241AP-2545/76
    Bolty MPR1 2825 LED 85W HP 8402825 x 60 x 80mm11218 lm353-241AP-2825/85

    Bolty SMPR1 low power

    TIP

    DIMENZIJE

    LUMEN

    ŠIFRA

    Bolty SMPR1 580 LED 10W LP 830580 x 60 x 80mm937 lm353-231AS-580/10
    Bolty SMPR1 860 LED 14W LP 830860 x 60 x 80mm1405 lm353-231AS-860/14
    Bolty SMPR1 1140 LED 18W LP 8301140 x 60 x 80mm1873 lm353-231AS-1140/18
    Bolty SMPR1 1420 LED 22W LP 8301420 x 60 x 80mm2342 lm353-231AS-1420/22
    Bolty SMPR1 1700 LED 27W LP 8301700 x 60 x 80mm2810 lm353-231AS-1700/27
    Bolty SMPR1 1985 LED 31W LP 8301985 x 60 x 80mm3278 lm353-231AS-1985/31
    Bolty SMPR1 2265 LED 35W LP 8302265 x 60 x 80mm3747 lm353-231AS-2265/35
    Bolty SMPR1 2545 LED 39W LP 8302545 x 60 x 80mm4215 lm353-231AS-2545/39
    Bolty SMPR1 2825 LED 43W LP 8302825 x 60 x 80mm4683 lm353-231AS-2825/43
    Bolty SMPR1 580 LED 10W LP 840580 x 60 x 80mm1044 lm353-241AS-580/10
    Bolty SMPR1 860 LED 14W LP 840860 x 60 x 80mm1566 lm353-241AS-860/14
    Bolty SMPR1 1140 LED 18W LP 8401140 x 60 x 80mm2088 lm353-241AS-1140/18
    Bolty SMPR1 1420 LED 22W LP 8401420 x 60 x 80mm2610 lm353-241AS-1420/22
    Bolty SMPR1 1700 LED 27W LP 8401700 x 60 x 80mm3132 lm353-241AS-1700/27
    Bolty SMPR1 1985 LED 31W LP 8401985 x 60 x 80mm3654 lm353-241AS-1985/31
    Bolty SMPR1 2265 LED 35W LP 8402265 x 60 x 80mm4175 lm353-241AS-2265/35
    Bolty SMPR1 2545 LED 39W LP 8402545 x 60 x 80mm4697 lm353-241AS-2545/39
    Bolty SMPR1 2825 LED 43W LP 8402825 x 60 x 80mm5219 lm353-241AS-2825/43

    Bolty SMPR1 high power

    TIP

    DIMENZIJA

    LUMEN

    ŠIFRA

    Bolty SMPR1 580 LED 18W HP 830580 x 60 x 80mm1875 lm353-231AS-580/18
    Bolty SMPR1 860 LED 26W HP 830860 x 60 x 80mm2812 lm353-231AS-860/26
    Bolty SMPR1 1140 LED 35W HP 8301140 x 60 x 80mm3749 lm353-231AS-1140/35
    Bolty SMPR1 1420 LED 43W HP 8301420 x 60 x 80mm4687 lm353-231AS-1420/43
    Bolty SMPR1 1700 LED 51W HP 8301700 x 60 x 80mm5624 lm353-231AS-1700/51
    Bolty SMPR1 1985 LED 59W HP 8301985 x 60 x 80mm6561 lm353-231AS-1985/59
    Bolty SMPR1 2265 LED 68W HP 8302265 x 60 x 80mm7499 lm353-231AS-2265/68
    Bolty SMPR1 2545 LED 76W HP 8302545 x 60 x 80mm8436 lm353-231AS-2545/76
    Bolty SMPR1 2825 LED 85W HP 8302825 x 60 x 80mm9373 lm353-231AS-2825/85
    Bolty SMPR1 580 LED 18W HP 840580 x 60 x 80mm2088 lm353-241AS-580/18
    Bolty SMPR1 860 LED 26W HP 840860 x 60 x 80mm3132 lm353-241AS-860/26
    Bolty SMPR1 1140 LED 35W HP 8401140 x 60 x 80mm4175 lm353-241AS-1140/35
    Bolty SMPR1 1420 LED 43W HP 8401420 x 60 x 80mm5219 lm353-241AS-1420/43
    Bolty SMPR1 1700 LED 51W HP 8401700 x 60 x 80mm6263 lm353-241AS-1700/51
    Bolty SMPR1 1985 LED 59W HP 8401985 x 60 x 80mm7307 lm353-241AS-1985/59
    Bolty SMPR1 2265 LED 68W HP 8402265 x 60 x 80mm8351 lm353-241AS-2265/68
    Bolty SMPR1 2545 LED 76W HP 8402545 x 60 x 80mm9395 lm353-241AS-2545/76
    Bolty SMPR1 2825 LED 85W HP 8402825 x 60 x 80mm10439 lm353-241AS-2825/85

    Bolty M2 low power

    TIP

    DIMENZIJA

    LUMEN

    ŠIFRA

    Bolty M2 580 LED 10W LP 830580 x 60 x 80mm895 lm353-431AM-580/10
    Bolty M2 860 LED 14W LP 830860 x 60 x 80mm1342 lm353-431AM-860/14
    Bolty M2 1140 LED 18W LP 8301140 x 60 x 80mm1789 lm353-431AM-1140/18
    Bolty M2 1420 LED 22W LP 8301420 x 60 x 80mm2237 lm353-431AM-1420/22
    Bolty M2 1700 LED 27W LP 8301700 x 60 x 80mm2684 lm353-431AM-1700/27
    Bolty M2 1985 LED 31W LP 8301985 x 60 x 80mm3132 lm353-431AM-1985/31
    Bolty M2 2265 LED 35W LP 8302265 x 60 x 80mm3579 lm353-431AM-2265/35
    Bolty M2 2545 LED 39W LP 8302545 x 60 x 80mm4026 lm353-431AM-2545/39
    Bolty M2 2825 LED 43W LP 8302825 x 60 x 80mm4474 lm353-431AM-2825/43
    Bolty M2 580 LED 10W LP 840580 x 60 x 80mm997lm353-441AM-580/10
    Bolty M2 860 LED 14W LP 840860 x 60 x 80mm1496 lm353-441AM-860/14
    Bolty M2 1140 LED 18W LP 8401140 x 60 x 80mm1994 lm353-441AM-1140/18
    Bolty M2 1420 LED 22W LP 8401420 x 60 x 80mm2493 lm353-441AM-1420/22
    Bolty M2 1700 LED 27W LP 8401700 x 60 x 80mm2991 lm353-441AM-1700/27
    Bolty M2 1985 LED 31W LP 8401985 x 60 x 80mm3490 lm353-441AM-1985/31
    Bolty M2 2265 LED 35W LP 8402265 x 60 x 80mm3988 lm353-441AM-2265/35
    Bolty M2 2545 LED 39W LP 8402545 x 60 x 80mm4487 lm353-441AM-2545/39
    Bolty M2 2825 LED 43W LP 8402825 x 60 x 80mm4986 lm353-441AM-2825/43

    Bolty M2 high power

    TIP

    DIMENZIJA

    LUMEN

    ŠIFRA

    Bolty M2 580 LED 18W HP 830580 x 60 x 80mm1791 lm353-431AM-580/18
    Bolty M2 860 LED 26W HP 830860 x 60 x 80mm2686 lm353-431AM-860/26
    Bolty M2 1140 LED 35W HP 8301140 x 60 x 80mm3581 lm353-431AM-1140/35
    Bolty M2 1420 LED 43W HP 8301420 x 60 x 80mm4477 lm353-431AM-1420/43
    Bolty M2 1700 LED 51W HP 8301700 x 60 x 80mm5372 lm353-431AM-1700/51
    Bolty M2 1985 LED 59W HP 8301985 x 60 x 80mm6268 lm353-431AM-1985/59
    Bolty M2 2265 LED 68W HP 8302265 x 60 x 80mm7163 lm353-431AM-2265/68
    Bolty M2 2545 LED 76W HP 8302545 x 60 x 80mm8058 lm353-431AM-2545/76
    Bolty M2 2825 LED 85W HP 8302825 x 60 x 80mm8954 lm353-431AM-2825/85
    Bolty M2 580 LED 18W HP 840580 x 60 x 80mm1994 lm353-441AM-580/18
    Bolty M2 860 LED 26W HP 840860 x 60 x 80mm2991 lm353-441AM-860/26
    Bolty M2 1140 LED 35W HP 8401140 x 60 x 80mm3988 lm353-441AM-1140/35
    Bolty M2 1420 LED 43W HP 8401420 x 60 x 80mm4986 lm353-441AM-1420/43
    Bolty M2 1700 LED 51W HP 8401700 x 60 x 80mm5983 lm353-441AM-1700/51
    Bolty M2 1985 LED 59W HP 8401985 x 60 x 80mm6980 lm353-441AM-1985/59
    Bolty M2 2265 LED 68W HP 8402265 x 60 x 80mm7977 lm353-441AM-2265/68
    Bolty M2 2545 LED 76W HP 8402545 x 60 x 80mm8974 lm353-441AM-2545/76
    Bolty M2 2825 LED 85W HP 8402825 x 60 x 80mm9971 lm353-441AM-2825/85

    Bolty MPR2 low power

    TIP

    DIMENZIJA

    LUMEN

    ŠIFRA

    Bolty MPR2 580 LED 10W LP 830580 x 60 x 80mm1007 lm353-431AP-580/10
    Bolty MPR2 860 LED 14W LP 830860 x 60 x 80mm1510 lm353-431AP-860/14
    Bolty MPR2 1140 LED 18W LP 8301140 x 60 x 80mm2013 lm353-431AP-1140/18
    Bolty MPR2 1420 LED 22W LP 8301420 x 60 x 80mm2516 lm353-431AP-1420/22
    Bolty MPR2 1700 LED 27W LP 8301700 x 60 x 80mm3020 lm353-431AP-1700/27
    Bolty MPR2 1985 LED 31W LP 8301985 x 60 x 80mm3523 lm353-431AP-1985/31
    Bolty MPR2 2265 LED 35W LP 8302265 x 60 x 80mm4026 lm353-431AP-2265/35
    Bolty MPR2 2545 LED 39W LP 8302545 x 60 x 80mm4530 lm353-431AP-2545/39
    Bolty MPR2 2825 LED 43W LP 8302825 x 60 x 80mm5033 lm353-431AP-2825/43
    Bolty MPR2 580 LED 10W LP 840580 x 60 x 80mm1122 lm353-441AP-580/10
    Bolty MPR2 860 LED 14W LP 840860 x 60 x 80mm1683 lm353-441AP-860/14
    Bolty MPR2 1140 LED 18W LP 8401140 x 60 x 80mm2244 lm353-441AP-1140/18
    Bolty MPR2 1420 LED 22W LP 8401420 x 60 x 80mm2804 lm353-441AP-1420/22
    Bolty MPR2 1700 LED 27W LP 8401700 x 60 x 80mm3365 lm353-441AP-1700/27
    Bolty MPR2 1985 LED 31W LP 8401985 x 60 x 80mm3926 lm353-441AP-1985/31
    Bolty MPR2 2265 LED 35W LP 8402265 x 60 x 80mm4487 lm353-441AP-2265/35
    Bolty MPR2 2545 LED 39W LP 8402545 x 60 x 80mm5048 lm353-441AP-2545/39
    Bolty MPR2 2825 LED 43W LP 8402825 x 60 x 80mm5609 lm353-441AP-2825/43

    Bolty MPR2 high power

    TIP

    DIMENZIJA

    LUMEN

    ŠIFRA

    Bolty MPR2 580 LED 18W HP 830580 x 60 x 80mm2015 lm353-431AP-580/18
    Bolty MPR2 860 LED 26W HP 830860 x 60 x 80mm3022 lm353-431AP-860/26
    Bolty MPR2 1140 LED 35W HP 8301140 x 60 x 80mm4029 lm353-431AP-1140/35
    Bolty MPR2 1420 LED 43W HP 8301420 x 60 x 80mm5036 lm353-431AP-1420/43
    Bolty MPR2 1700 LED 51W HP 8301700 x 60 x 80mm6044 lm353-431AP-1700/51
    Bolty MPR2 1985 LED 59W HP 8301985 x 60 x 80mm7051 lm353-431AP-1985/59
    Bolty MPR2 2265 LED 68W HP 8302265 x 60 x 80mm8058 lm353-431AP-2265/68
    Bolty MPR2 2545 LED 76W HP 8302545 x 60 x 80mm9066 lm353-431AP-2545/76
    Bolty MPR2 2825 LED 85W HP 8302825 x 60 x 80mm10073 lm353-431AP-2825/85
    Bolty MPR2 580 LED 18W HP 840580 x 60 x 80mm2244 lm353-441AP-580/18
    Bolty MPR2 860 LED 26W HP 840860 x 60 x 80mm3365 lm353-441AP-860/26
    Bolty MPR2 1140 LED 35W HP 8401140 x 60 x 80mm4487 lm353-441AP-1140/35
    Bolty MPR2 1420 LED 43W HP 8401420 x 60 x 80mm5609 lm353-441AP-1420/43
    Bolty MPR2 1700 LED 51W HP 8401700 x 60 x 80mm6731 lm353-441AP-1700/51
    Bolty MPR2 1985 LED 59W HP 8401985 x 60 x 80mm7852 lm353-441AP-1985/59
    Bolty MPR2 2265 LED 68W HP 8402265 x 60 x 80mm8974 lm353-441AP-2265/68
    Bolty MPR2 2545 LED 76W HP 8402545 x 60 x 80mm10096 lm353-441AP-2545/76
    Bolty MPR2 2825 LED 85W HP 8402825 x 60 x 80mm11218 lm353-441AP-2825/85

    Bolty SMPR2 low power

    TIP

    DIMENZIJA

    LUMEN

    ŠIFRA

    Bolty SMPR2 580 LED 10W LP 830580 x 60 x 80mm937 lm353-431AS-580/10
    Bolty SMPR2 860 LED 14W LP 830860 x 60 x 80mm1405 lm353-431AS-860/14
    Bolty SMPR2 1140 LED 18W LP 8301140 x 60 x 80mm1873 lm353-431AS-1140/18
    Bolty SMPR2 1420 LED 22W LP 8301420 x 60 x 80mm2342 lm353-431AS-1420/22
    Bolty SMPR2 1700 LED 27W LP 8301700 x 60 x 80mm2810 lm353-431AS-1700/27
    Bolty SMPR2 1985 LED 31W LP 8301985 x 60 x 80mm3278 lm353-431AS-1985/31
    Bolty SMPR2 2265 LED 35W LP 8302265 x 60 x 80mm3747 lm353-431AS-2265/35
    Bolty SMPR2 2545 LED 39W LP 8302545 x 60 x 80mm4215 lm353-431AS-2545/39
    Bolty SMPR2 2825 LED 43W LP 8302825 x 60 x 80mm4683 lm353-431AS-2825/43
    Bolty SMPR2 580 LED 10W LP 840580 x 60 x 80mm1044 lm353-441AS-580/10
    Bolty SMPR2 860 LED 14W LP 840860 x 60 x 80mm1566 lm353-441AS-860/14
    Bolty SMPR2 1140 LED 18W LP 8401140 x 60 x 80mm2088 lm353-441AS-1140/18
    Bolty SMPR2 1420 LED 22W LP 8401420 x 60 x 80mm2610 lm353-441AS-1420/22
    Bolty SMPR2 1700 LED 27W LP 8401700 x 60 x 80mm3132 lm353-441AS-1700/27
    Bolty SMPR2 1985 LED 31W LP 8401985 x 60 x 80mm3654 lm353-441AS-1985/31
    Bolty SMPR2 2265 LED 35W LP 8402265 x 60 x 80mm4175 lm353-441AS-2265/35
    Bolty SMPR2 2545 LED 39W LP 8402545 x 60 x 80mm4697 lm353-441AS-2545/39
    Bolty SMPR2 2825 LED 43W LP 8402825 x 60 x 80mm5219 lm353-441AS-2825/43

    Bolty SMPR2 high power

    TIP

    DIMENZIJA

    LUMEN

    ŠIFRA

    Bolty SMPR2 580 LED 18W HP 830580 x 60 x 80mm1875 lm353-431AS-580/18
    Bolty SMPR2 860 LED 26W HP 830860 x 60 x 80mm2812 lm353-431AS-860/26
    Bolty SMPR2 1140 LED 35W HP 8301140 x 60 x 80mm3749 lm353-431AS-1140/35
    Bolty SMPR2 1420 LED 43W HP 8301420 x 60 x 80mm4687 lm353-431AS-1420/43
    Bolty SMPR2 1700 LED 51W HP 8301700 x 60 x 80mm5624 lm353-431AS-1700/51
    Bolty SMPR2 1985 LED 59W HP 8301985 x 60 x 80mm6561 lm353-431AS-1985/59
    Bolty SMPR2 2265 LED 68W HP 8302265 x 60 x 80mm7499 lm353-431AS-2265/68
    Bolty SMPR2 2545 LED 76W HP 8302545 x 60 x 80mm8436 lm353-431AS-2545/76
    Bolty SMPR2 2825 LED 85W HP 8302825 x 60 x 80mm9373 lm353-431AS-2825/85
    Bolty SMPR2 580 LED 18W HP 840580 x 60 x 80mm2088 lm353-441AS-580/18
    Bolty SMPR2 860 LED 26W HP 840860 x 60 x 80mm3132 lm353-441AS-860/26
    Bolty SMPR2 1140 LED 35W HP 8401140 x 60 x 80mm4175 lm353-441AS-1140/35
    Bolty SMPR2 1420 LED 43W HP 8401420 x 60 x 80mm5219 lm353-441AS-1420/43
    Bolty SMPR2 1700 LED 51W HP 8401700 x 60 x 80mm6263 lm353-441AS-1700/51
    Bolty SMPR2 1985 LED 59W HP 8401985 x 60 x 80mm7307 lm353-441AS-1985/59
    Bolty SMPR2 2265 LED 68W HP 8402265 x 60 x 80mm8351 lm353-441AS-2265/68
    Bolty SMPR2 2545 LED 76W HP 8402545 x 60 x 80mm9395 lm353-441AS-2545/76
    Bolty SMPR2 2825 LED 85W HP 8402825 x 60 x 80mm10439 lm353-441AS-2825/85

    Zatražite tehničku dokumenataciju
